SG9

$0.01

Category: Silver oxide

Description

Nominal Voltage 1.55V
Capacity 45mAh (Discharge at 1KΩ to 0.9V )
Dimensions 9.5mm D x 3.6mm H
Weight 0.87g
UNIT/PACK 5
MASTER INNER/PKS 50/20
MASTER PKS/PCS 1000/5000
MASTER SIZE (LxWxH) 15.4″x11.4″x11.8″
MASTER CU FT 1.2
MASTER WEIGHT (LBS) 21.38



LOAD RESISTANCE TESTS

Load Resistance 1KΩ 22KΩ
Discharge Method Continuous Continuous
End Point Voltage 0.9V 1.2V
Typical Discharge Duration 34.5 Hrs 800 Hrs
