| Packaging |
Six pieces of high quality 3350mAh Lithium 18650 cells with Protection Circuit Module (PCM) |
| Nominal Voltage |
7.2V |
| Capacity |
Typical |
10.05Ah (0.2C discharge) |
| Minimum |
9045mAh |
| Max. Current |
Charge |
Recommend Maximum 5A |
| Discharge |
6 A continuous Discharge |
| Ambient temperature |
Charge |
0 deg C to 45 deg C |
| Discharge |
-20 deg C to 60 deg C |
| Storage |
-5 deg C to 35 deg C |
| One Protection Circuit Module |
Overcharge |
>12.6V |
| Overdischarge |
<7.5V |
| Current Protection |
16-20A |
| Short Circuit |
Protection |
| Thermistor |
|
Optional |
| Approx. Weight (g) |
368g |
| Dimensions |
approx. 57mm L x 38mm W x 70mm H |
| Wiring & Connection |
2 wires (length=6″, size=18AWG) cable with red (+) and black (- or com). |
